PRO-300 / TURBO















PRO-300

40 CH AM/FM CB TRANSCEIVER SILVER

FEATURE



FUNCTION
1. AM/FM  SW
2. SCAN SW
3. CH-9 (RESET) SW
120CH>>band "L0W>CB>HIGH"
4. UP SW
5. DOWN SW

CONTROLS
1. AF VOLUME CONTROL, W/ ON / OFF SW
2. SQUELCH VOLUME CONTROL

LCD DISPLAY
1. CHANNEL-2DIGIT
2. TX
3. AM/FM
4. SC
5. L , H

3.5 PIE EXT SPEAKER JACK
M-TYPE ANT CONNECTOR
4 PIN MIC JACK C-MIC, PTT SW
BILT-IN  AUTOMATIC NOISE LIMIT
DIMENSION : W-140mm . D-125mm . H-41mm.
WEIGHT :     g.(gift total :  g)



ELECTRICAL



GENERAL
@ TRANSMITTER......... CRSTAL CONTROLLED PLL SYNTHESIZER
@ RECEIVER.................... DOUBLE CONVERSION, SUPERHETERODYNE SYSTEM
@ VOLTAGE OPERATION......... DC 13.8 V
@ TEMPERATURE........................ -10 ℃ ~ +50 ℃
@ CHANNEL STEP ..................... 10 Khz

TRANSMITTER
@ OUTPUT POWER........................... FM/AM :  4WATTS HP :FM/AM  :  6WATTS (EU:5W)
@ FREQUENCY RANGE................... 26.965 ~ 27.405 MHz
LOW BAND :26.515 ~  26.955 MHz
CB  BAND  :26.965 ~ 27.405 MHz
HI   BAND : 27.415 ~  27.855 MHz
@ FREQUENCY TOLERANCE........ +-500 Hz
@ MODULATION SENS.................... 10mV(1.25KHz INPUT:C-MIC)
@ MODULATION CAPABLITY...... AM : 90 %
FM : 2 KHz

RECEIVER
@ SENSITIVITY.................................... AM : 0.5 uV(S/N 10dB)
FM : 0.3 uV (SINAD12dB)
@ SQUELCH............................................ 0.5uV MAX
@ S/N RATIO......................................... 45 dB
@ DISTORTION.....................................  5 %
@ MAX POWER....................................  5 WATTS

TEST CONDITION
@ POWER SOURCE............................. DC 13.8 VOLTS
@ ANT LOAD IMPEDANCE............ 50 ohm NON-INDUCTIVE
@ AUDIO LOAD IMPEDANCE.......  8 ohm NON-INDUCTIVE
